Sain (サイン)

A Compose Multiplatform library for capturing and exporting signatures as ImageBitmap with customizable options. Perfect
for electronic signature, legal documents and more.

See the project's website for documentation.

Sample Usage

var imageBitmap by remember {
    mutableStateOf<ImageBitmap?>(null)
}

Sain(
    signatureHeight = 250.dp,
    signaturePadColor = Color.White,
    signatureBorderStroke = BorderStroke(
        width = .5.dp,
        color = MaterialTheme.colorScheme.onSurface,
    ),
    signaturePadShape = RoundedCornerShape(8.dp),
    onComplete = { signatureBitmap ->
        if (signatureBitmap != null) {
            imageBitmap = signatureBitmap
        } else {
            println("Signature is empty")
        }
    },
) { action ->
    Row(
        modifier = Modifier
            .padding(top = 16.dp)
            .fillMaxWidth(),
        horizontalArrangement = Arrangement.spacedBy(16.dp),
    ) {
        Button(
            modifier = Modifier.weight(1f),
            onClick = {
                imageBitmap = null
                action(SignatureAction.CLEAR)
            },
        ) {
            Text("Clear")
        }
        Button(
            modifier = Modifier.weight(1f),
            onClick = {
                action(SignatureAction.COMPLETE)
            },
        ) {
            Text("Complete")
        }
    }
}

Base64 Encoding for ImageBitmap

To make it easier to store or transfer ImageBitmap across platforms in a format that is platform-independent, we provide a utility to convert ImageBitmap to a Base64 string. This functionality is useful in scenarios like signature storage or image uploads.

Add the following lines to your commonMain, androidMain, and iosMain modules to implement this feature.

Implementation

commonMain

In commonMain, define the expect function:

expect fun ImageBitmap.toBase64(): String

androidMain

In androidMain, implement the actual function:

actual fun ImageBitmap.toBase64(): String {
    val bitmap = this.asAndroidBitmap()
    val byteArrayOutputStream = ByteArrayOutputStream()
    bitmap.compress(Bitmap.CompressFormat.PNG, 100, byteArrayOutputStream)
    val byteArray = byteArrayOutputStream.toByteArray()
    return Base64.encodeToString(byteArray, Base64.NO_WRAP)
}

Note: The asAndroidBitmap() extension function is from androidx.compose.ui.graphics.

iosMain

In iosMain, implement the actual function:

@OptIn(ExperimentalForeignApi::class)
fun ImageBitmap.toUIImage(): UIImage? {
    val width = this.width
    val height = this.height
    val buffer = IntArray(width * height)

    this.readPixels(buffer)

    val colorSpace = CGColorSpaceCreateDeviceRGB()
    val context = CGBitmapContextCreate(
        data = buffer.refTo(0),
        width = width.toULong(),
        height = height.toULong(),
        bitsPerComponent = 8u,
        bytesPerRow = (4 * width).toULong(),
        space = colorSpace,
        bitmapInfo = CGImageAlphaInfo.kCGImageAlphaPremultipliedLast.value
    )

    val cgImage = CGBitmapContextCreateImage(context)
    return cgImage?.let { UIImage.imageWithCGImage(it) }
}

actual fun ImageBitmap.toBase64(): String {
    val uiImage = this.toUIImage()
    val jpegData = uiImage?.let { UIImageJPEGRepresentation(it, 0.5) }
        ?: return ""
    return jpegData.base64Encoding()
}

Usage

To use this function in your multiplatform project:

val base64String = imageBitmap.toBase64()
// Store or transfer the `base64String` as needed
